WattMaster WHP Section 3
Programming 3-5
If you selected menu item #1 View Status Only and you entered the Unit ID of an
installed WHP Controller, the following Status Screens are available.
Status Screen #1
Status Screen #2
Line 2 - Current Zone Temperature
Line 3 -
Current Cooling Setpoint ( CSP
) and Heating
Setpoint ( HSP )
Line 4 - Effect of optional Sensor Slide Adjustment on the
current operating setpoints.
WSHPRV 1 V2.03
Space Temp.:xxx.x
°
F
CSP xx.x
°
HSP xx.x
°
Slide Adjust: x.x
°
F
Line 2 -
Current Supply Air Temperature
Line 3 - Current Leaving Water Temperature if Sensor is
installed.
Line 4 - Current Outdoor Air Temperature.
WSHPRV 1 V2.03
Supply Air.:xxx.x
°
F
Water Temp.:xxx.x
°
F
Outdoor Air:xxx.x
°
F
