WattMaster WHP Section 3
Programming 3-25
Status Screen #5
Status Screen #6
Note: If none of the above options have been configured, then the values in this status
screen will be 0.
Cool Stage # 5.: OFF
Cool Stage # 6.: OFF
Cool Stage # 7.: OFF
Cool Stage # 8.: OFF
Loop Control v1.06
Pressure.: xxx.x PSI
Pump VFD.: xx.x VDC
Heat VFD.: xx.x VDC
Line 2 - Current Loop Water Pressure
Line 3 - Current Variable Speed Pump Voltage Signal
Line 4 -
Current Proportional Heat Voltage Signal
Line 1 -
Cool/Heat Stage #5 On/Off
Line 2 -
Cool/Heat Stage #6 On/Off
Line 3 -
Cool/Heat Stage #7 On/Off
Line 4 -
Cool/Heat Stage #8 On/Off
