Section 3 WattMaster WHP
3-6 Programming
Status Screen #3
Status Screen #4
Status Screen #5
WSHPRV 1 V2.03
Occupied Mode
Fan Status...: ON
Operations Enabled
Line 2 - Current Operating Status
Unoccupied Mode
Occupied Mode
Pushbutton Override
Forced Occupied
Forced Unoccupied
Forced Fan Only Mode
Line 3 - Current Fan Status
Fan Start Delay!
ON
OFF
Line 4 - Current Enable Status from Loop
Controller
Operations Disabled
Operations Enabled
Line 2 -
Current Compressor ON/OFF Status
Line 3 - Current Reversing Valve ON/OFF Status
Line 4 - Current Status of Relay #5. Operation
depends on how the user configures this
output.
WSHPRV 1 V2.03
Compressor...: ON
Reverse Valve: OFF
Aux / Stage#2: OFF
Line 2 -
Current HVAC Operating Mode
Neutral Mode
Cooling Mode
Heating Mode
Line 3 -
Reserved for future option.
Line 4 - Reserved for future option.
WSHPRV 1 V2.03
Cooling Mode
