Heat Controller Water Source Heat Pump - Manual (Page 72)

Section 3 WattMaster WHP
3-24 Programming
Status Screen #2
Status Screen #3
Status Screen #4
Loop Control v1.06
No Call to Run
Water Flow Proved!
LOOP ENABLED
Line 2 - Current operating Mode:
No Call To Run
ACTIVE CALL TO RUN
FREEZE PROTECTION!
Line 3 -
Current Water Flow Status:
Water Flow Proved!
No Flow Detected
Line 4 - Current Request to Operate Status:
LOOP ENABLED
LOOP DISABLED
Loop Control v1.06
LEAD Pump #1: ON
STANDBY Pump #2: OFF
Line 2 -
LEAD Pump #1 On or Off
Line 3 -
STANDBY Pump #2 On or Off
Line 1 -
Cool/Heat Stage #1 On/Off
Line 2 -
Cool/Heat Stage #2 On/Off
Line 3 -
Cool/Heat Stage #3 On/Off
Line 4 -
Cool /Heat Stage #4 On/Off
Cool Stage # 1.: OFF
Cool Stage # 2.: OFF
Cool Stage # 3.: OFF
Cool Stage # 4.: OFF
