Hp smart array p400i controller cabling, Pci smart array controller cabling – HP DL365 User Manual
Page 59
Cabling 59
HP Smart Array P400i Controller cabling
CAUTION:
When routing cables, use the cable trough between fan modules 1 and 2. Be sure
the cables do not interfere with fan module installation. Be sure to route the cables around the
DIMM connectors so as not to interfere with DIMM installation.
PCI Smart Array controller cabling
CAUTION:
When routing cables, use the cable trough between fan modules 1 and 2. Be sure
the cables do not interfere with fan module installation. Be sure to route the cables around the
DIMM connectors so as not to interfere with DIMM installation.
IMPORTANT:
When using a PCI array controller, be sure to remove the integrated array
controller.
