Illustrated parts catalog 20
Item Description Spare part
number
Customer
self repair
(on page
5 )
k) 3.0-GHz, 95-W AMD Opteron™* 451810-001 Optional 2
11 Heatsink with grease and alcohol swab 431356-001 Optional 2
Boards
12 HP Smart Array controllers — —
a) HP Smart Array E200i Controller, integrated SAS 412205-001 Mandatory 1
b) HP Smart Array P400i Controller, integrated SAS 412206-001 Mandatory 1
13 System board with processor cages 431355-001 Optional 2
14 SAS backplane 412201-001 Optional 2
15 Multibay media backplane 412202-001 Mandatory 1
16 HP Systems Insight Display, LEDs, and power button assembly,
with cable
431358-001 Optional 2
Media devices
17 Multibay drives — —
a) CD-RW combo drive, removable multibay, IDE, 24X 399959-001 Mandatory 1
b) DVD-ROM+RW drive, removable multibay, 8X* 397928-001 Mandatory 1
c) Diskette drive, removable multibay* 399396-001 Mandatory 1
Memory
18 DIMM, PC2-5300 registered DDR2 — —
a) 512-MB* 430449-001 Mandatory 1
b) 1-GB* 430450-001 Mandatory 1
c) 2-GB* 432668-001 Mandatory 1
d) 4-GB* 432670-001 Mandatory 1
Hard drives
19 SAS hard drives — —
a) 36-GB, 10,000-rpm 376596-001 Mandatory 1
b) 72-GB, 10,000-rpm* 376597-001 Mandatory 1
c) 146-GB, 10,000-rpm* 432320-001 Mandatory 1
20 60-GB SATA hard drive, 5,400-rpm* 405419-001 Mandatory 1
BBWC
21 HP Smart Array E200i battery pack 307132-001 Optional 2
22 HP Smart Array P400i battery pack 398648-001 Optional 2
23 HP Smart Array E200i memory module, 64-MB* 412800-001 Optional 2
24 HP Smart Array E200i memory module, 128-MB* 413486-001 Optional 2
25 HP Smart Array P400i memory module, 256-MB* 405836-001 Optional 2
26 HP Smart Array P400i memory module, 512-MB* 405835-001 Optional 2
