Cabling 58
Cabling
Cabling overview
This section provides guidelines that help you make informed decisions about cabling the server and
hardware options to optimize performance.
For information on cabling peripheral components, refer to the white paper on high-density deployment at
CAUTION:
When routing cables, always be sure that the cables are not in a position where
they can be pinched or crimped.
Array controller cabling
Depending on the primary controller installed, various cabling configurations exist:
•
HP Smart Array E200i Controller cabling (on page
•
HP Smart Array P400i Controller cabling (on page
•
PCI Smart Array controller cabling (on page
•
Battery pack cabling (on page
HP Smart Array E200i Controller cabling
CAUTION:
When routing cables, use the cable trough between fan modules 1 and 2. Be sure
the cables do not interfere with fan module installation. Be sure to route the cables around the
DIMM connectors so as not to interfere with DIMM installation.
