High End Systems Power Cue DMX User Manual
Page 19
When you call a group into a scene, all channels will be set at full brightness. Having
called the group you can then change the level of individual channels by selecting chan-
nels in the scene programming menu.
14
1.
Press SetUp. Enter the SetUp passcode, if
prompted.
2.
Press Group.
4.
Press one of the sixteen illuminated push
buttons. This is where the groups will reside.
5.
Scroll through the channels and
assign/remove channels, using the
appropriate button. Selected (assigned)
channels show *. During programming
selected channels are output at full
brightness.
Press STORE when you have finished
selecting channels for this group.
SET UP GROUPS
Where you need to use certain channels together on a regular basis, you will find it easier and quick-
er to call them into a scene as one group, rather than many individual channels. This routine shows
you how to define the channels in a group. You may define a total of 16 groups.
TIP!
