Page 29
Configuration and diagnostics 29
•
*1 Internal Use. Program will not generate this error.
HP NC-Series Broadcom 10 GbE adapter diagnostics
The eDiag utility operates in an MS-DOS environment. It includes a DOS extender (PMODE/W) that is
embedded into the executable and provides access to memory above 1MB.
Please note that diagnostics are not available for adapters that have FlexNIC enabled.
To execute the user diagnostic utility in DOS, complete the following steps:
1.
Change to the apps\diags\ediag folder where the softpaq was extracted.
2.
From your DOS prompt, enter the following executable file to run the eDiag tool:
uediag.exe
•
Command lines are performed by default on all devices installed on the machine. If the devices are
selected by –dev or –c options, the command line performs on the selected devices only.
•
For command line options –fnvm, -fbc, -fl2b, -fipmi, and -fump, the command line is performed on the
primary devices only because these are shared options between ports.
For example, on a two-port adapter, the –fnvm option is performed on port 0 only because there is
no need to repeat the non-volatile memory (NVM) programming on port 1.
The following table provides command line options that are the available in the eDiag diagnostic tool.
For example, enter the following command line options:
eDiag –log results.log –rc regress.tcl
The diagnostic utility logs the test execution results in a file called results.log and specifies the
regress.tcl script after startup.
Options Description
-rc
