169
A
ddi
tiona
l I
n
fo
rm
at
ion
Effective picture elements (16:9 mode):
Approx. 14,200,000 pixels
Color temperature
Preset (Indoor: 3200K, Outdoor: 5600K
±
7 steps, Color temperature set range:
2300 to 15000K), One-push A, B, Auto
selectable
Minimum illumination
When [60i] is selected:
1.7 lux (LOW LUX mode is on, 1/30
sec. shutter speed, 33 dB gain)
When [50i] is selected:
1.7 lux (LOW LUX mode is on, 1/25
sec. shutter speed, 33 dB gain)
Lens
Lens mount
Fixed
Zoom ratio
12× (optical), servo
Focal length
9.3 mm to 111.6 mm
(35 mm equivalent (16:9)
29.0 mm to 348.0 mm)
(35 mm equivalent (3:2)
32.8 mm to 393.6 mm)
Iris
F2.8 to F4.5
(auto/manual selectable)
Focus
AF/MF selectable,
10 mm to
∞
(Wide),
1000 mm to
∞
(Tele)
Image stabilizer
On/Off selectable, lens-shift type
Filter diameter
M62 mm
Wireless LAN
Supported standard
IEEE 802.11a/b/g/n/ac
Frequency band
2.4 GHz/5 GHz
(5 GHz band is supported on the PXW-
Z90V only)
Supported security protocols
WEP/WPA-PSK/
WPA2-PSK
NFC Forum Type 3 Tag compliant
Input/output connectors
VIDEO OUT jack
Multi/Micro USB jack (1)
Composite 1.0 Vp-p, 75
Ω
AUDIO OUT jack
Multi/Micro USB jack (1)
HDMI OUT jack
Type A (1)
SDI jack
BNC jack (1)
USB jack
Multi/Micro USB jack (1)
i (headphone) jack
Stereo mini jack (
∅
3.5 mm) (1)
INPUT1/INPUT2 jacks
XLR-type 3-pin (female) (2)
line/mic/mic+48V selectable
MIC jack (PLUG IN POWER)
Stereo mini jack (
∅
3.5 mm) (1)
Multi Interface Shoe (1)
REMOTE jack
Stereo sub-mini jack (
∅
2.5 mm) (1)
Screen
LCD screen
8.8 cm (3.5 inch type)
Approx. 1.56M dots
Viewfinder
1.0 cm (0.39 inch type) OLED
Approx. 2.36M dots
Continued ,
