Reference 104S v2 ♦ ProLinx Gateway
Protocol Manual (Firmware v2.xx)
ProSoft Technology, Inc.
Page 107 of 157
March 19, 2010
5.1.3 Hardware Specifications
Specification Description
Power Supply 24 VDC nominal
18 to 32 VDC allowed
Positive, Negative, GND Terminals
2.5 mm screwdriver blade
Current Load 500 mA max @ 32 VDC max
Operating Temperature -4° F to 122° F (-20° C to 50° C)
Storage Temperature -40° F to 185° F (-40° C to 85° C)
Relative Humidity 5 to 95% (without condensation)
Dimensions
(Height x Width x
Depth) Standard: 5.20 in x 2.07 in x 4.52 in
(13.2 cm x 5.25 cm x 11.48 cm)
Extended: 5.20 in x 2.73 in x 4.52 in
(13.2 cm x 6.934 cm x 11.48 cm)
LED Indicators
(On all gateways) Power and Hardware Fault
Configuration and Application Communication Status
Serial Configuration Port Activity and Error
Configuration
Serial Port DB-9M RS-232 only
No hardware handshaking
Ethernet Port
(Ethernet protocol
gateways only) 10Base-T half-duplex RJ45 Connector
Link LED and Activity LED indicators
Electrical Isolation 1500 V rms at 50 Hz to 60 Hz for 60 s,
applied as specified in section 5.3.2 of IEC 60950: 1991
Ethernet Broadcast Storm Resiliency = less than or equal
to 5000 [ARP] frames-per-second and less than or equal to
5 minutes duration
Application Serial
Port(s)
(Serial protocol
gateways only) RS-232/422/485
RS-232 handshaking configurable
RS-422/485 DB-9 to Screw Terminal Adaptor
Note: The number of serial application ports depends on
the gateway type, and the combination of protocols.
Serial Port Isolation 2500 V RMS port signal isolation per UL 1577
3000 VDC min. isolation port to ground and port to logic
Shipped with Each Unit Mini-DIN to DB-9M serial cables
4-foot RS-232 configuration cable
2.5mm screwdriver
CD (docs and Configuration utility)
RS-422/485 DB-9 to Screw Terminal Adapter for each
serial application port (serial protocols only)
