MVI56E-DNPNET ♦ ControlLogix Platform Contents
DNPNET Ethernet Client/Server Communication Module User Manual
ProSoft Technology, Inc. Page 33 of 140
February 13, 2015
Tag Name Range Description
DNPNET.CONFIG.DNP3_Ser
ver. Spare1_Always_2
0 to 255 retries Maximum number of retries at the Data Link
level to obtain a confirmation. If this value is
set to 0, retries are disabled at the data link
level of the protocol. This parameter is only
used if the frame is sent with confirmation
requested.
DNPNET.CONFIG.DNP3_Ser
ver.App_Layer_Confirm_Tout
1 to 32767
milliseconds
Event data contained in the last response may
be sent again if not confirmed within the
millisecond time period set. If application layer
confirms are used with data link confirms,
ensure that the application layer confirm
timeout is set long enough.
DNPNET.CONFIG.DNP3_Ser
ver.Unsolicited_Response
0 or 1 If set to 0, the server will not send unsolicited
responses. If set to 1, the server will send
unsolicited responses.
DNPNET.CONFIG.DNP3_Ser
ver.Class_1_Unsol_Resp_Min
1 to 255 events Minimum number of events in Class 1 required
before an unsolicited response will be
generated.
DNPNET.CONFIG.DNP3_Ser
ver.Class_2_Unsol_Resp_Min
1 to 255 events Minimum number of events in Class 2 required
before an unsolicited response will be
generated.
DNPNET.CONFIG.DNP3_Ser
ver.Class_3_Unsol_Resp_Min
1 to 255 events Minimum number of events in Class 3 required
before an unsolicited response will be
generated.
DNPNET.CONFIG.DNP3_Ser
ver.Unsol_Resp_Delay
1 to 32767
milliseconds
Maximum number of 1 millisecond intervals to
wait after an event occurs before sending an
unsolicited response message. If set to 0, only
use minimum number of events.
DNPNET.CONFIG.DNP3_Ser
ver.UResp_Client_Address
0 to 255 retries DNP destination address where unsolicited
response messages are sent.
DNPNET.CONFIG.DNP3_Ser
ver.AnalogInput_Events_with_t
ime
0 or 1 This parameter sets if the analog input events
generated by the module will include the date
and time of the event. If the parameter is set to
0, the default is set to no time data. If the
parameter is set to 1, the default object will
include the time of the event.
DNPNET.CONFIG.DNP3_Ser
ver.Events_Require_Time_Sy
nc
0 or 1 This parameter is used to determine if events
will be generated by the server module when
its time is not synchronized from a client. If the
parameter is set to 1, no events will be
generated until the module's time has been
synchronized. If the parameter is set to 0,
events will always be generated.
DNPNET.CONFIG.DNP3_Ser
ver.Initialize_DNP_Output_Dat
abase
0 or 1 This parameter determines if the module will
request data from the processor to initialize the
DNP database output data areas. If this option
is utilized, ladder logic is required to send the
requested blocks from the processor to the
module.
