47
1. Click “iSCSI” tab and Click “Add” to create an iSCSI target on the NAS.
2. Enter the iSCSI target information for configuration
Item Description
Target User Name The name for the target.
iSCSI Target Lun Select to create an iSCSI target with a mapped LUN and enter the
size of LUN
Comment The comment for the target.
iSCSI
Authentication
None or CHAP
Target User Name The name for target authentication
Password The password for target authentication
Mutual CHAP Two-way authentication mode
Initiator Name The name for initiator authentication
Password The password for initiator authentication
CRC/Checksum Data or Header Digest
3. Apply the settings. Now, an iSCSI LUN is a logical volume mapped to the iSCSI target. The
target and LUN are shown on the list under the “iSCSI” tab.
Note: The NAS supports 8 iSCSI devices at maximum.
4. The LANs created can be mapped to and unmapped from the iSCSI target anytime. You can
deactivate or activate by clicking or icon, respectively. You can delete a target by
clicking icon.
