25A Switch Mode Rectifier  NT5C06B / C Installation and User Manual
Specifications
Mechanical
The MPR25 or MPR15 rectifiers have the following dimensions:
• Height: 168 mm (6.60 inches)
• Depth: 260 mm (10.25 inches)
• Width: 149 mm (5.85 inches)
Electrical
Rectifier voltage and current
The input current requirements of the MPR15 / MPR25 rectifier and the
NT5C10 power shelves are listed in Table 3:
Table 3 - MPR15/MPR25 input current requirements
Input voltage:
frequency
range
120 V AC
47-63 Hz
96-132 V AC
208 V AC
47-63 Hz
176-264 V AC
240 V AC
47-63 Hz
176-264 V AC
1. MPR15 10.5 A (16.5 A) n/a n/a
2. MPR25 n/a 11.7 A (15.5 A) 10.2 A (15.5 A)
NT5C10 Shelf:
(a) 2 rectifiers 21.0 A (33.0 A) 23.4 A (31.1 A) 20.4 A (31.1 A)
3.
(b) 3 rectifiers 31.5 A (49.5 A) 35.1 A (46.6 A) 30.6 A (46.6 A)
Condition: Typical input current value for 54 V dc, full load output =
maximum input current at Output 54V DC, current limit
minimum line.
Input protection: 20 A AC breaker
