User’s Manual of GS-4210-24P2S
 Approved PLANET SFP Transceivers
PLANET PoE Managed Switch supports both Single mode and Multi-mode SFP transceiver. The following list of approved
PLANET SFP transceivers is correct at the time of publication:
Gigabit SFP Transceiver Modules
 MGB-GT SFP-Port 1000Base-T Module
 MGB-SX SFP-Port 1000Base-SX mini-GBIC module
 MGB-LX SFP-Port 1000Base-LX mini-GBIC module -10KM
 MGB-L30 SFP-Port 1000Base-LX mini-GBIC module -30KM
 MGB-L50 SFP-Port 1000Base-LX mini-GBIC module -50KM
 MGB-L70 SFP-Port 1000Base-LX mini-GBIC module -70KM
 MGB-L120 SFP-Port 1000Base-LX mini-GBIC module -120KM
 MGB-LA10 SFP-Port 1000Base-LX (WDM,TX:1310nm) -10KM
 MGB-LB10 SFP-Port 1000Base-LX (WDM,TX:1550nm) -10KM
 MGB-LA20 SFP-Port 1000Base-LX (WDM,TX:1310nm) -20KM
 MGB-LB20 SFP-Port 1000Base-LX (WDM,TX:1550nm) -20KM
 MGB-LA40 SFP-Port 1000Base-LX (WDM,TX:1310nm) -40KM
 MGB-LB40 SFP-Port 1000Base-LX (WDM,TX:1550nm) -40KM
Fast Ethernet SFP Transceiver Modules
 MFB-FX SFP-Port 100Base-FX Transceiver -2KM
 MFB-F20 SFP-Port 100Base-FX Transceiver -20KM
 MFB-F40 SFP-Port 100Base-FX Transceiver -40KM
 MFB-F60 SFP-Port 100Base-FX Transceiver -60KM
 MFB-FA20 SFP-Port 100Base-BX Transceiver (WDM,TX:1310nm) -20KM
 MFB-FB20 SFP-Port 100Base-BX Transceiver (WDM,TX:1550nm) -20KM
It is recommended to use PLANET SFP on the PoE Managed Switch. If you insert an SFP
transceiver that is not supported, the PoE Managed Switch will not recognize it.
In the installation steps below, this Manual uses Gigabit SFP transceiver as an example. However,
the steps for Fast Ethernet SFP transceiver are similar.
1. Before we connect PoE Managed Switch to the other network device, we have to make sure both sides of the SFP
transceivers are with the same media type, for example: 1000Base-SX to 1000Base-SX, 1000Bas-LX to 1000Base-LX.
2. Check whether the fiber-optic cable type matches with the SFP transceiver requirement.
 To connect to 1000Base-SX SFP transceiver, please use the multi-mode fiber cable with one side being the male
duplex LC connector type.
 To connect to 1000Base-LX SFP transceiver, please use the single-mode fiber cable with one side being the male
duplex LC connector type.
