User’s Manual of GS-4210-24P2S
The page includes the following fields:
Object Description
 Port The switch port number of the logical port.
Display the current egress rate limit. 
Egress Rate Limit
(Kbps)
4.8.5.4 Egress Queue Settings
The Egress Queue Badwidth Control Settings and Status screens in Figure 4-8-37 & Figure 4-8-38 & Figure 4-8-39 appear.
Figure 4-8-37: Egress Queue BandwidthSettings Page Screenshot
The page includes the following fields:
Object Description
 Burst Size Allow assigning burst size and the options are 1 to 65535. Unit: Bytes.
 Port Select port number for this drop down list.
 Queue Select queue numbers for this drop down list, options are 1 to 8.
 State Enable or disable the port rate policer. The default value is "Disabled".
Configure the CIR for the port policer. The default value is "unlimited". Valid
values are in the range 0 to 1000000, must a multiple of 16.

CIR (Kbps)
Button
: Click to apply changes.
190
