User’s Manual of GS-4210-24P2S
4.9.3.9 Option82 Circuit-ID Setting
Set creation method for option82, users can define the parameters of circute-id suboption by themselves. Option82 Circuit-ID
Setting screens in Figure 4-9-27 & Figure 4-9-28 appear.
Figure 4-9-27: Option82 Port Circuit-ID Setting Page Screenshot
The page includes the following fields:
Object Description
 Port Select port for this drop down list.
 VLAN Indicates the ID of this particular VLAN.
Set the option1 (Circuit ID) content of option 82 added by DHCP request packets.  Circuit ID
Button
: Click to apply changes.
Figure 4-9-28: Option82 Port Circuit-ID Setting Page Screenshot
The page includes the following fields:
Object Description
 Port Display the current port.
 VLAN Display the current VLAN.
 Circuit ID Display the current circuit ID.
218
