9 Starting up the Powador-protect
9.1 Switching on Powador-protect
↻ The device has been mounted and electrically installed.
1. Connect the AC power supply and AC measurement inputs via
external fuse elements.
2. Start up the PV system in line with the installation instructions.
» The device begins the grid monitoring process and connects
the PV system when the limit values are observed.
9.2 Sealing the Powador-protect (optional)
↻ The device is mounted, electrically installed and configured.
1. Close the device cover.
2. Run sealing wire through the opening on the device cover
and fit a closure.
9.3 Performing a self test
The Powador-protect supports the testing of the tripping circuit "NA
protection - tie circuit-breaker" in accordance with VDE AR-N 4105 in
the "Germany" country setting. The digital output "Inverter off" and
any connected tie circuit-breakers are actuated.
� Press and hold the test button (>1s).
» The self test is carried out. The "Processing manual event..."
message appears on the display.
» The device begins grid measurement and re-connects the PV
system according to the waiting time set "Tstart".
