SMA America, LLC 13 Technical Data
Installation Manual SB3-5TLUS22-IA-en-16 87
Efficiency
13.1.6 Sunny Boy 7000TL-US
DC Input
AC Output
Nominal AC current at 240 V 25 A
Maximum output current 25,2 A
Maximum overcurrent protection 40 A
Total harmonic distortion ≤ 4%
Nominal AC frequency 60 Hz
AC frequency range at 60 Hz nominal 59.3 Hz to 60.5 Hz
Power factor at rated power 1
Connection conductor 2
Output connections L1, L2, N, PE
Maximum efficiency, η
max
97.4%
CEC efficiency, η
CEC
at 208 V AC nominal 96.5%
CEC efficiency, η
CEC
at 240 V AC nominal 97.0%
Maximum DC operating power 7,300 W
Maximum system voltage 600 V
Rated MPP tracking voltage range at 208 V AC 210 V to 480 V
Rated MPP tracking voltage range at 240 V AC 245 V to 480 V
Rated operating voltage 400 V
Minimum operating voltage 125 V
Start voltage, no-load status 125 V
Maximum input current 30 A
Maximum input current per MPP tracking input 18 A
Maximum short-circuit current per MPP tracking
input 19 A
MPP tracking inputs 2
Strings per MPP tracking input 2
Rated power at 208 V, 60 Hz 6,000 W
Rated power at 240 V, 60 Hz 7,000 W
Maximum apparent power at 208 V, 60 Hz 6,000 VA
Maximum apparent power at 240 V, 60 Hz 7,000 VA
