13 Technical Data SMA America, LLC
86 SB3-5TLUS22-IA-en-16 Installation Manual
Efficiency
13.1.5 Sunny Boy 6000TL-US
DC Input
AC Output
Total harmonic distortion ≤ 4%
Nominal AC frequency 60 Hz
AC frequency range at 60 Hz nominal 59.3 Hz to 60.5 Hz
Power factor at rated power 1
Connection conductor 2
Output connections L1, L2, N, PE
Maximum efficiency, η
max
97.6%
CEC efficiency, η
CEC
at 208 V AC nominal 96.5%
CEC efficiency, η
CEC
at 240 V AC nominal 97.0%
Maximum DC operating power 6,300 W
Maximum system voltage 600 V
Rated MPP tracking voltage range 210 V to 480 V
Rated operating voltage 400 V
Minimum operating voltage 125 V
Start voltage, no-load status 150 V
Maximum input current 30 A
Maximum input current per MPP tracking input 15 A
Maximum short-circuit current per MPP tracking
input 19 A
MPP tracking inputs 2
Strings per MPP tracking input 2
Rated power at 208 V, 60 Hz 5,200 W
Rated power at 240 V, 60 Hz 6,000 W
Maximum apparent power at 208 V, 60 Hz 5,300 VA
Maximum apparent power at 240 V, 60 Hz 6,100 VA
Nominal AC voltage 208 V / 240 V
AC voltage range at 208 V nominal 183 V to 229 V
AC voltage range at 240 V nominal 211 V to 264 V
Nominal AC current at 208 V 25 A
