Working with the pattern generator – HEIDENHAIN iTNC 530 (340 49x-02) Pilot User Manual
Page 115
115
Defining
Mach
ining
Posit
io
ns
Working with the pattern generator
Overview
The following possibilities are available in the pattern generator for
defining machining positions:
Function
Soft key
Page
Single point, Cartesian
Single row, straight or arced
Pattern straight, arced or distorted
Frame straight, arced or distorted
Full circle
Circular arc
Change starting height
