Selecting a Board Location
DVCPRO Upgrade Installation 57
Table 10. Board I/O requirements and restrictions for a PDR200 with DVCPRO boards
Board Video Router
Connection
Requirements
Recommended
Slots
Other
Possible
Slots
Comments
Inputs Outputs
CPU n/a n/a J1 None Reserved for PC card only. PC/VGA/LAN
combination board in S/N B050000 and Up.
VGA n/a n/a J2 None ISA only. Parallel port in S/N B050000 and Up
LAN n/a n/a J3 None EISA connection only. May be empty in
S/N B050000 and Up.
SCSI n/a n/a J4 None EISA connection only
RefGen n/a n/a J16 None Reference genlock
RS-422 n/a n/a J17 None EISA only
Master EDR 2 2 J10 None Must be adjacent to Fibre Channel (if installed).
5 slot PCI Interconnect required.
Slave EDR 2 2 J8 None Must be adjacent to Fibre Channel (if installed).
5 slot PCI Interconnect required.
Fibre Channel None None J9 None Must be adjacent to Master EDR in slot J10. 5
slot PCI Interconnect required.
DVCPRO
CODEC (4-codec) 4 4 J11 None Must be adjacent to Master EDR board in slot
J10. 5 slot PCI Interconnect required.
DVCPRO
CODEC (2-codec) 2 2 J12 None Must be in slot J12. 5 slot PCI Interconnect
required.
Analog Composite
In None 1 J6, J15 J5-15 Any open slot if board in adjacent slot does not
use the same shared router points. Must be
adjacent to the Analog Composite Decoder.
Analog Composite
Decoder None None J5, J14 J4-15 Must be adjacent to Analog Composite In.
May be installed in J4 since it does not require
any router connections.
Analog Composite
I/O 2 2 J13, J14, J15 J5-J15 Any open slot if board in adjacent slot does not
use the same shared router points.
Four Channel
Analog Out 4 None J6, J7 J6, J7 Only J6 and J7 have 4 inputs and are available
in a DVCPRO PDR200.
Analog Composite
Monitor Out 4 None J6, J7 J6, J7 Only J6 and J7 have 4 inputs and are available
in a DVCPRO PDR200.
Serial Digital I/O 2 2 J14, J15 J6, J7, J13 Cables must be able to reach ASPBs
CAV In None 1 J6 J5-15 Any open slot if board in adjacent slot does not
use the same shared router points.
Mix Effects 6 2 J6 J7 Only J6 and J7 have 5 inputs; board must be
able to get a shared input (the 6th) from an
adjacent slot (J5 or J8)
Audio Signal
Processing Board
(ASPB) None None J5 (1st)
J7 (2nd)
J5-J15 Any open slot since it requires no video router
connections. Cables must be able to reach video
boards or additional ASPB. Second ASPB
necessary for 32 channels of audio.
