Installing Boards in an Early PDR200 Unit
DVCPRO Upgrade Installation 35
4. Install the five-slotted PCI Interconnect board. This board is a high-speed
bus used to move data between boards with PCI connectors. Align the center
keys on the PCI Interconnect board with the keys on the Master EDR board
in slot J10. Using appropriate pressure, press down firmly on the
interconnect board to ensure that it is properly seated (see Figure 6 on
page 29).
5. Connect the audio clock and Sharcnet cables according to the diagram you
drew earlier or see “Connecting Audio Clock and Sharcnet Cables” on
page 41.
6. Follow the reassembly instructions under the heading “Reassembling the
Profile Chassis” on page 36.
WARNING: To avoid personal injury from electrical shock and/or damage to
disk drives, do not apply power until all covers are in place and secured.
!!
