DVCPRO Board Installation
44 DVCPRO Upgrade Installation
Three Serial Digital I/O Boards and Two ASPBs
The example in Table 6 and Figure 10 shows audio clock and Sharcnet cabling for
a PDR204D having three Serial Digital I/O boards and two ASPBs.
Table 6. Cabling for three Serial Digital I/O boards and two ASPBs
Cable Type Serial Digital
I/O Slot Serial Digital I/O
Connection ASPB 1
Connection
(J5) ASPB 2
Connection
(J7)
Sharcnet N/A N/A Sharcnet
Expansion 2 Sharcnet
Expansion 1
Sharcnet N/A N/A Sharcnet
Expansion 1 Sharcnet
Expansion 2
Sharcnet J13 Sharcnet In Sharcnet Out 1 N/A
Sharcnet J13 Sharcnet Out Sharcnet In 1 N/A
Sharcnet J14 Sharcnet In Sharcnet Out 2 N/A
Sharcnet J14 Sharcnet Out Sharcnet In 2 N/A
Sharcnet J15 Sharcnet In N/A Sharcnet Out 1
Sharcnet J15 Sharcnet Out N/A Sharcnet In 1
Audio clock J13 Channel A Audio 1 N/A
Audio clock J13 Channel B Audio 2 N/A
Audio clock J14 Channel A Audio 3 N/A
Audio clock J14 Channel B Audio 4 N/A
Audio clock J15 Channel A N/A Audio 1
Audio clock J15 Channel B N/A Audio 2
