DVCPRO Board Installation
48
DVCPRO Upgrade Installation
Three Analog I/O Boards and Two ASPBs
The example in Table 8 and Figure 12 shows audio clock cabling for a PDR204A
having three Analog Composite I/O boards and two ASPBs.
Table 8. Cabling for three Serial Digital I/O boards and two ASPBs
Cable Type
Analog
Composite
I/O Board
Slot
Analog
Composite I/O
Board
Connection
ASPB 1
Connection
(J5)
ASPB 2
Connection
(J7)
Sharcnet N/A
N/A
Sharcnet
Expansion 2
Sharcnet
Expansion 1
Sharcnet N/A
N/A
Sharcnet
Expansion 1
Sharcnet
Expansion 2
Audio clock
J13
Channel A
Audio 1
N/A
Audio clock
J13
Channel B
Audio 2
N/A
Audio clock
J14
Channel A
Audio 3
N/A
Audio clock
J14
Channel B
Audio 4
N/A
Audio clock
J15
Channel A
N/A
Audio 1
Audio clock
J15
Channel B
N/A
Audio 2
