4. Install the DVCPRO boards as follows:
a. If you have a four-codec DVCPRO CODEC board (PDFDV04 kit) install
it in slot J11.
b. If you have a two-codec DVCPRO CODEC board (PDFDV02 kit) install
it in slot J12. If you already have a board in slot J12, remove it to install
the DVCPRO CODEC board.
5. Reinstall any video I/O or audio boards that you had to remove to make room
for other boards. (For information on appropriate slots for video and audio
boards, see “Board Location Guide” on page 53.)
6. Install the board bracket screws. Use the Torx tool with the T15 tip to install
the mounting screws in the top of the board bracket inside thechassis
(
Ê in Figure 4 on page 27) and through the rear panel at the bottom of the
board bracket (
7. Connect the SCSI cables, as shown in Figure 5 on page 28.
8. Install the five-slotted PCI Interconnect board. This board is a high-speed
bus used to move data between boards with PCI connectors. Align the center
keys on the PCI Interconnect board with the keys on the Master EDR board
in slot J10. Using appropriate pressure, press down firmly on the
interconnect board to ensure that it is properly seated (see Figure 6 on
page 29).
9. Connect the audio clock and Sharcnet cables according to the diagram you
drew earlier or see “Connecting Audio Clock and Sharcnet Cables” on
page 41.
10. Follow the reassembly instructions under the heading “Reassembling the
CAUTION: To avoid personal injury from electrical shock and/or damage to
disk drives, do not apply power until all covers are in place and secured.
!!
