DVCPRO Board Installation
24 DVCPRO Upgrade Installation
Installing the DVCPRO Boards
This section describes how to install the DVCPRO boards in the PDR200. In this
procedure, you will be instructed to remove the three-slotted PCI Interconnect
board and replace it with the five-slotted board provided in this upgrade kit. The
center slot on the five-slotted PCI board must be aligned with the Master EDR
board in slot J10. All other boards connecting to the PCI Interconnect board must
be installed in the board slots shown in Table 3.
If you have an Option DV (DVCPRO-ready) PDR200, the circuit boards are
already in the required board slots. All you have to do is install the DVCPRO
boards. Other PDR200 configurations require moving boards to other slot
locations to free up the required slots. For this reason, there are three procedures
in this section which give step by step instructions for all the possible PDR 200
configurations.
Refer to Table 4 to determine which procedure you should follow, then proceed.
Table 3. Board locations
Board Required
Board Slots
Slave EDR J8
Fibre Channel (if installed) J9
Master EDR J10
DVCPRO CODEC (PDFDV04) J11
DVCPRO CODEC (PDFDV02) J12
