DVCPRO Board Installation
54 DVCPRO Upgrade Installation
Video Router I/O Connections
Now let’s look at the video router connections available at slots J5–J15. Table 9
shows a board location worksheet that shows the video router input and output
connections. The worksheet is blank except for the 5 board slots reserved for the
boards that are connected by the PCI Interconnect board. In this chart:
• The Slot column lists each slot on the motherboard connected to the video
router.
• The Board column is where you write the boards currently installed and the
name of the board you want to install.
• The Input column identifies input connections available to the installed
boards from the video router. The numbers in the blocks correspond to the
order input connections are assigned at the video router connector.
• The Output column identifies output connections available from the
installed boards to the video router. The numbers in the blocks correspond to
the order output connections are assigned at the video router connector.
• The shaded blocks in the diagram indicate video router connections shared
between slots. A shared connection is available to either slot, but not both at
the same time. For instance:
- The shaded input blocks between slots J5 and J6, slots J7 and J8, slots J10
and J11, and slots J12 and J13 indicate shared input connections.
- The shaded output blocks between slots J8 and J9, slots J10 and J11, and
slots J12 and J13 indicate shared output connections.
