DVCPRO Board Installation
46
DVCPRO Upgrade Installation
Two Analog Composite I/O Boards and One ASPB
The example in Table 7 and Figure 11 shows audio clock cabling for a PDR204A
having two Analog Composite I/O boards and one ASPB.
Table 7. Cabling for two Analog Composite I/O boards and one ASPB
Cable Type
Analog
Composite I/O
Board
Slot
Analog
Composite I/O
Board
Connection
ASPB1
Connection
(J5)
Audio clock
J14
Channel A
Audio 1
Audio clock
J14
Channel B
Audio 2
Audio clock
J15
Channel A
Audio 3
Audio clock
J15
Channel B
Audio 4
