Aspb audio clock and sharcnet cabling examples – Grass Valley DVCPRO Board Upgrade User Manual
Page 45
ASPB Audio Clock and Sharcnet Cabling Examples
DVCPRO Upgrade Installation
45
Figure 10. ASPB cabling with three Serial Digital I/O boards and two ASPBs
0516-9
PCI Interconnect Bd.
(Do not place cabling
on top of board.)
Audio 1
Audio 2
Audio 3
Audio 4
Sharcnet Out 1
Sharcnet Out 2
Sharcnet In 2
Sharcnet In 1
Sharcnet
Expansion 1
Sharcnet
Expansion 2
Sharcnet In
Sharcnet Out
ASPB2
ASPB1
Serial
Digital I/O
J1
J17
J13
J16
J15 J14
J6
J7
J4 J3 J2
J5
J12 J11
J9 J8
J10
Two-codec
DVCPRO (PDFDV02)
Four-codec
DVCPRO (PDFDV04)
Channel A
Channel B
Slave EDR
Fibre Channel
Master EDR
