DVCPRO Board Installation
42 DVCPRO Upgrade Installation
ASPB Audio Clock and Sharcnet Cabling Examples
This section shows four ASPB cabling examples that cover most DVCPRO
configurations for the PDR 200. Find the example that matches your system and
use it to reconnect the ASPB cabling. Even though some board locations may be
different than yours, the cabling rules remain the same.
Two Serial Digital I/O Boards and One ASPB
The example in Table 5 and Figure 9 shows audio clock and Sharcnet cabling for
a PDR204D having two Serial Digital I/O boards and one ASPB.
Table 5. Cabling for two Serial Digital I/O boards and one ASPB
Cable Type Serial Digital
I/O Slot Serial Digital I/O
Connection ASPB1
Connection
(J5)
Sharcnet J14 Sharcnet In Sharcnet Out 1
Sharcnet J14 Sharcnet Out Sharcnet In 1
Sharcnet J15 Sharcnet In Sharcnet Out 2
Sharcnet J15 Sharcnet Out Sharcnet In 2
Audio clock J14 Channel A Audio 1
Audio clock J14 Channel B Audio 2
Audio clock J15 Channel A Audio 3
Audio clock J15 Channel B Audio 4
