09 April 2010 K2 Summit Production Client Service Manual 63
Reorder adapters
4. Do one of the following:
• If you intend to use SiteConfig for device discovery and IP address
configuration, you do not need to set an IP address for the Control Team at this
time. Skip ahead to the last step in this procedure.
• If you are not using SiteConfig, set an IP address for the Control Team at this
time. Use standard Windows procedures.
Do not set IP addresses for the two Media Connections.
5. If continuing with network configuration, proceed with the next procedure
“Reorder adapters” . If network configuration is complete, enable the write filter.
Reorder adapters
1. If you have not already done so, disable the write filter.
2. On the Windows desktop right-click My Network Places and select Properties .
The Network Connections window opens.
3. On the menu bar at the top of the window, select Advanced , then Advanced
Settings…
4. On the Adapters and Bindings tab, depending on the K2 Summit Client’s storage,
order adapters as follows:
If controlled by Dyno Production Assistant, refer to Dyno PA documentation for
adapter order.
5. Click OK to close Advanced settings and accept the changes.
6. Close the Network Properties window.
7. If continuing with network configuration, proceed with the next procedure “Set
power management settings” . If network configuration is complete, enable the
write filter.
In the Device Name column, select this adapter name… And rename it as follows:
TEAM : Control Team Control Team
Microsoft Loopback Adapter Loopback
Internal or direct-connect storage Shared (SAN) storage
Loopback Control Team
Control Team Media Connection #1
Media Connection #1 Media Connection #2
Media Connection #2 Loopback
Control Connection #1 Control Connection #1
Control Connection #2 Control Connection #2
1394 Connection 1394 Connection
