136 8995UPC/DNC/UDX — Instruction Manual
Active Format Description
Table 25 gives the Auto aspect ratio mode input and output codes for Input
Frame = 16:9/Output Frame = 4:3 with each of the alignment choices:
Center , Top , Bottom , Left , and Right .
Table 25. Mode = Auto, Input Frame = 16:9, Output Frame = 4:3
Input Frame = 16:9, Output Frame = 4:3
Mode = Auto
Alignment Choices
Center Top Bottom Left Right
Input
Code Output
Code
Scalar
Mode
Input
Code Output
Code
Scalar
Mode
Input
Code Output
Code
Scalar
Mode
Input
Code Output
Code
Scalar
Mode
Input
Code Output
Code
Scalar
Mode
0000 0000
Full
Height
0000 0000
Full
Height
0000 0000
Full
Height
0000 0000
Full
Height
0000 0000
Full
Height
0001 0000
Full
Height
0001 0000
Full
Height
0001 0000
Full
Height
0001 0000
Full
Height
0001 0000
Full
Height
0010 0000
Full
Height
0010 1010
Full
Height
0010 0000
Full
Height
0010 0000
Full
Height
0010 0000
Full
Height
0011 0000
14x9
SP
0011 1011
14x9
SP
0011 0000
14x9
SP
0011 0000
14x9
SP
0011 0000
14x9
SP
0100 0100
Full
Height
0100 0100
Full
Height
0100 0000
Full
Height
0100 0000
Full
Height
0100 0000
Full
Height
0101 0000
Full
Height
0101 0000
Full
Height
0101 0000
Full
Height
0101 0000
Full
Height
0101 0000
Full
Height
0110 0000
Full
Height
0110 0000
Full
Height
0110 0000
Full
Height
0110 0000
Full
Height
0110 0000
Full
Height
0111 0000
Full
Height
0111 0000
Full
Height
0111 0000
Full
Height
0111 0000
Full
Height
0111 0000
Full
Height
1000 1000
Full
Height
1000 1000
Full
Height
1000 1000
Full
Height
1000 1000
Full
Height
1000 1000
Full
Height
1001 1000
Full
Height
1001 1000
Full
Height
1001 1000
Full
Height
1001 0000
Full
Height
1001 0000
Full
Height
1010 1000
Full
Height
1010 1000
Full
Height
1010 1000
Full
Height
1010 1000
Full
Height
1010 1000
Full
Height
1011 1011
14x9
SP
1011 1011
14x9
SP
1011 0000
14x9
SP
1011 0000
14x9
SP
1011 0000
14x9
SP
1100 0000
Full
Height
1100 0000
Full
Height
1100 0000
Full
Height
1100 0000
Full
Height
1100 0000
Full
Height
1101 1101
Full
Height
1101 1101
Full
Height
1101 1101
Full
Height
1101 0000
Full
Height
1101 0000
Full
Height
1110 1110
Full
Height
1110 1110
Full
Height
1110 1000
Full
Height
1110 0000
Full
Height
1110 1000
Full
Height
1111 1111
Full
Height
1111 1111
Full
Height
1111 1000
Full
Height
1111 0000
Full
Height
1111 0000
Full
Height
