112 8995UPC/DNC/UDX — Instruction Manual
Configuration Summary Table
Video Input Selection COAX
COAX,
Fiber RX 1,
or Fiber RX 2
Video Input/
Video Input Select
Video Input Selection
radio button
N/A
Horizontal Timing control 0 See Table 7 on page 60
Frame Sync/
Timing Adjustment/
Horizontal Timing (pixels)
HTiming
Vertical Timing control 0 see Table 7 on page 60
Frame Sync/
Timing Adjustment
Vertical Timing (lines)
VTiming
Multi-Frame Delay control 0 0 to 6 Frames
Frame Sync/
Timing Adjustment
Multi-Frame Delay (Frames)
MultFrmDly
Minimum Delay Mode enable Disabled Enable or Disable
Frame Sync/
Minimum Delay Mode
Enable checkbox
MinDly
Loss of signal operation
(Output timing set to Local, Ref 1,
or Ref 2)
AutoBlue
Pass
Auto Freeze, or
Auto Blue
Frame Sync/
Loss of Signal Operation
radio button
LOS Oper
Manual freeze mode None
None,
Frame, or
Field
Frame Sync/
Manual Freeze Mode
radio button
ManFrzMode
Adjust R gain 100%
0 to 200%
(1% steps)
Color Correction/
R Gain (%)
R Gn
Adjust G gain 100%
0 to 200%
(1% steps)
Color Correction/
G Gain (%)
G Gn
Adjust B gain 100%
0 to 200%
(1% steps)
Color Correction/
B Gain (%)
B Gn
Adjust total gain 100%
0 to 200%
(1% steps)
Color Correction/
RGB Gain
RGB Gn
Adjust R offset 0
±100%
(1% steps)
Color Correction/
R Offset (%)
R Off
Adjust G offset 0
±100%
(1% steps)
Color Correction/
G Offset (%)
G Off
Adjust B offset 0
±100%
(1% steps)
Color Correction/
B Offset (%)
B Off
Adjust total offset 0
0 to 200%
(1% steps)
Color Correction/
RGB Offset
RGB Off
Adjust R gamma 1.0
0.25 to 4.00
(0.01 unit steps)
Color Correction/
R Gamma Correction
RGmC
Adjust G gamma 1.0
0.25 to 4.00
(0.01 unit steps)
Color Correction/
G Gamma Correction
GGmC
Adjust B gamma 1.0
0.25 to 4.00
(0.01 unit steps)
Color Correction/
B Gamma Correction
BGmC
Adjust total gamma 100
0.25 to 4.00
(0.01 unit steps)
Color Correction/
Total Gamma Correction
RGBGmC
Adjust Y gain (contrast) 100%
0 to 200%
(1% steps)
Video Proc/
Video Processing Controls
Y Gain (%)
Y Gain
Adjust color saturation
(chroma gain)
100%
0 to 200%
(1% steps)
Video Proc/
Video Processing Controls
Color Saturation (%)
Chro Gn
Adjust total gain 100%
0 to 200%
(1% steps)
Video Proc/
Video Processing Controls
Total Gain
VPA Gain
Table 13. Summary of 8995UDX/UPC/DNC Configuration Functions
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
Newton
Control
Panel
