SS3GR24i/SS3GR48i Layer3 Stackable Gigabit Switch User’s Guide
VID The VLAN ID number of the VLAN on which
the above MAC address resides.
MAC Address The MAC address to which packets will be
statically forwarded.
Click Apply to add the entry.
To delete an entry, repeat the steps above starting with the VLAN
ID and then enter the MAC address, click Apply to delete.
The Table at the bottom of the page lists all Static FDB Entries,
showing the Port, VLAN ID and MAC Address of each entry, click
Next Page and Previous Page to cycle through the table listings.
FDB by Port
The FDB by Port Page allows viewing of the FDB MAC Addresses
on a port basis. It also has a setting for the Age-Out Time, this
field specifies the length of time a learned MAC Address will
remain in the forwarding table without being accessed (how long a
learned – not static – address can remain idle). This is a global
setting for the switch and will change the number for all ports and
also the number listed in the FDB by MAC and FDB by VID Pages.
The setting ranges from 10-1000000 seconds, the default is 300 sec.
To access the FDB by Port Page click the Spanning Tree Folder,
then click the Forwarding DB Subfolder.
90
