SS3GR24i/SS3GR48i Layer3 Stackable Gigabit Switch User’s Guide
Shared Secret Type the shared-secret key used by the
Radius server and the switch. Up to 20
characters can be used.
Response Time The time interval in seconds that the
switch waits for the RADIUS server to
reply before retransmitting
Maximum
Retransmission
The number of times a RADIUS
request is re-sent to the server, range
is 1 to 254
802.1x
The IEEE 802.1x standard IEEE is used as a basis for
authentication on all 802 networks, using a client and server based
access protocol, this is done using a RADIUS server. A RADIUS
server authenticates users trying to access a network by relaying
Extensible Authentication Protocol over LAN (EAPOL) packets
between the Client and the Server. The settings for the server were
configured in the above page. To configure 802.1x settings, click
the Ports Folder, and then the Port Security Subfolder and finally
the 802.1x Page.
72
