OnLine Power PBC I User Manual
Page 40
Appendix B: INSTALLATION ACCESSORY KIT PAD/POLE MOUNT PARTS LIST
For 220, 230 VAC and 50 Hz -- PBC
DESCRIPTION
QTY
PART NO.
½ FLEXIBLE LIQUID TIGHT CONDUIT (FOR ALARM CABLE)
14 FT
½ LIQUID FLEXIBLE METAL SEAL RING
2
T&B 5262
½ LIQUID FLEXIBLE METAL CONDUIT FITTINGS, 90
1
T&B 5352
½ LIQUID FLEXIBLE METAL CONDUIT FITTINGS, STR
1
T&B 5332
1” FLEXIBLE LIQUID TIGHT CONDUIT
14 FT
1” LIQUIDTIGHT FLEXIBLE METAL CONDUIT SEAL RING
2
T&B 5264
1” LIQUIDTIGHT FLEXIBLE METAL CONDUIT FITTINGS, 90
1
T&B 5354
1” LIQUIDTIGHT FLEXIBLE METAL CONDUIT FITTINGS, STR
1
T&B 5334
AC POWER CABLES 10 AWG,
20 FT
THHN-BRN-10 -STR
AC POWER CABLES 10 AWG
20 FT
THHN-BLU-10 -STR
AC POWER CABLES 10 AWG
20 FT
THHN-GRN/YL-10 -STR
6 AWG GREEN GROUND INSULATED CONDUCTOR 6
FT
THHN-GRN-6-STR
M6 x 1.0 x 20 MM LONG, STAINLESS STEEL HEX BOLT
4
M6 STAINLESS STEEL, LOCKWASHER
4
M6 STAINLESS STEEL, FLATWASHER
4
6 AWG TO 2 AWG C-TAP CU
2
2 HOLE COMPRESSION LUG 6 AWG CU .75 CENTER TO CNTR
2
1” METAL CLAMP
7
½” METAL CLAMP
7
CONNECTOR 1
HEYCO
P/N
3214
ALARM CABLE, DB 9, 20 FT
1
NOTES:
1. INTERCONNECTION
HARDWARE
BETWEEN THE UPS AND SERVICE ENTRANCE
IS NOT INCLUDED IN THSIS KIT.
2. ALL CONDUCTORS SHALL BE COPPER.
33
