3-4 PBC Installation - Installation of PBC has the following steps:
• The unpacking of PBC covered in section 3.1 & 3.2.
• The PBC installation and mounting.
• Connecting of conduit to PBC cabinet.
• Connecting DB-9 to control panel.
• Wiring input power to unit TB-1.
• Wiring output power from unit TB-2.
• Powering up the PBC unit & testing it.
• Power up the output circuits & checking loading.
3-5 Lifting Requirements
• Use Load - Rated Snaps on end of chain and a Spreader Bar.
CAUTION !
• Because the PBC Cabinets and it's contents, batteries, transformers, etc.… are extremely heavy, the use
of Power Equipment is necessary.
• Total weight for 650W Model is 365 lbs.
• Electronic Tray weight is approximately 55 lbs.
• The Battery Tray weight, with a set of 4 batteries, is approximately 200 lbs.
• Power Backup Cabinet weight is approximately 85 lbs.
• Pole/Wall mount adapter plates with hardware is approximately 28 lbs.
• Pad/Roof adapter plates with hardware is approximately 14 lbs.
• Total weight for 1300W Model is 455 lbs.
• Electronic Tray weight is approximately 57 lbs.
• A Battery Tray with a set of 6 batteries weighs approximately 290 lbs.
• Power Backup Cabinet weight is approximately 85 lbs.
• Pole/Wall mount adapter plates with hardware is approximately 28 lbs.
• Pad/Roof adapter plates with hardware is approximately 14 lbs.
CAUTION !
At least two persons should lift the battery tray and the electronics tray.
