Belt Clip
Product Reference Guide A-11
Figure A-9. Installing the Belt Clip
Attaching to a Belt
To attach the Pegaso to a belt, snap the Belt Attachment onto your Belt. Slide the Pegaso
onto the Belt Attachment sideways, then rotate to an upright position to secure it into
place, as shown in Figure
A-10 .
Figure A-10. Attaching to a Belt
Belt
Clip
Locked
Position
Unlocked
Position
1/4 Turn Latch
