Accessories
A-8 Pegaso™ Industrial PDA with Windows ® CE
Figure A-8. Removing/Replacing the Handstrap
Installing the Handstrap
To install a Handstrap on the Pegaso, follow the steps described below.
1. Feed the strap end of the handstrap down through the Back Enclosure Handstrap
Holder slot as shown in Figure A-8 and loop it up to engage the closure area at the
desired position.
2. Attach the Upper Handstrap Assembly to the unit using the two Phillips screws.
Handle
The Pegaso is available with an attachable handle
which provides an additional trigger for scanning.
When you remove the handle, you lose the ability
to press the trigger on the handle and must use the
key on the keypad or Scan triggers on the
Pegaso instead.
To install a handle, refer to the following sections.
Reverse the instructions to remove the handle.
Handstrap
Back Enclosure
Handstrap Holder
Closure Area
Upper
Handstrap
Assembly
The Handstrap can be left on when installing the
Handle.
