Programming Parameters
F-10 Pegaso™ Industrial PDA with Windows ® CE
If RSS-14, RSS-Expanded, RSS-Limited, or RSS-Composite symbologies are enabled for UCC-EAN
128, then that setting is also enabled for all other RSS symbologies.
NOTE: For the 2D Imager, RSS-Expanded User Code ID is used for RSS-14
RSS Limited
Enter 1 for On
and 0 for Off.
RSS Limited
Enable
Enables/disables the RSS Limited symbology. 0808 On / Off Off On On
RSS Limited
to UCC-EAN
128 Instructs the decoder to transmit the label data
as one or more UCC-128 labels. The trans-
mission will use the UCC-128 AIM identifier.
080C On / Off Off On Off
If RSS-14, RSS-Expanded, RSS-Limited, or RSS-Composite symbologies are enabled for UCC-EAN
128, then that setting is also enabled for all other RSS symbologies.
NOTE: For the 2D Imager, RSS-Expanded User Code ID is used for RSS-Limited
RSS Expanded
Enter 1 for On
and 0 for Off.
RSS
Expanded
Enable
Enables/disables the RSS Expanded symbol-
ogy.
0810 On / Off Off On On
RSS
Expanded to
UCC-EAN
128
Instructs the decoder to transmit the label data
as one or more UCC-128 labels. The trans-
mission will use the UCC-128 AIM identifier.
0804 On / Off Off On Off
RSS
Expanded
Minimum
Set the minimum bar code label length to be
less than or equal to maximum label length.
0824 1 - 74 1 74 1
RSS
Expanded
Maximum
This feature specifies the maximum allowable
length of a label. The length includes check
and data characters, if applicable. Maximum
Label Length should be greater than or equal
to Minimum Label Length.
0825 1 - 74 1 74 74
RSS
Expanded
User Code ID
Specifies the symbology identifier (if any) that
is sent when parameter Send Code ID (Index
0025) is set to 3. "ASCII" code zero (null) is
used to indicate that an identifier is not to be
sent for the symbology.
0827
Any single
ASCII char-
acter (00 =
Off)
‘R’ ‘R’ ‘R’
Code Parameter/ Description I.D. #
Acceptable
Input
Defaults
Min Max Factory
