Step-by-step, Starting situation framework design – Ivoclar Vivadent IPS InLine System User Manual
Page 16
16
Step-by-step
Maxillary and mandibular model articulated in the “Stratos 200”
Design the framework in a reduced supported shape.
Starting situation for metal-supported IPS InLine restorations
Starting situation
framework design
Design the framework with a reduced anatomical shape taking the planned layering into account. The wall thickness for
single crowns should be at least 0.3 mm and at least 0.5 mm for abutment crowns.
Make sure to provide sufficient stability of shape for the framework. Avoid sharp transitions and edges. Design the
connector areas between the individual units in such a stable way that they meet the requirements of interdental hygiene
and the alloy used.
