Gasboy FiPay Server Retrofit Kit for 8-hose Islander User Manual
Page 7
MDE-5045 FiPay™ Server Retrofit Kit for 8-hose Islander Installation Guide · January 2013
Page 7
Installing the FiPay Server and Additional Hardware Components in the 8-hose Islander PLUS System
2
Remove the screws/staples from both sides of the box (see
).
Figure 3: Removing the Screws/Staples
Screw on Side of the Box
Staple on Side of the Box
(i)
(ii)
