Page 6 MDE-4096C Blackmer® Global Dispenser Pump Operation, Maintenance and Kit Installation Manual · April 2008
Installation
Installation
Inlet Fittings
The Blackmer GDP is shipped without inlet fittings. Appropriate inlet fittings must be
installed on site.
Configuration Table
The following table lists three possible inlet configurations.
Sl. No Inlet Configuration
1 1-1/2” NPT x 1-3/4” LG. SCH. 80 NIPPLE and 1-1/2” NPT 150# Union (Gilbarco part
numbers R11493-50 and K12179)
2 1-1/2” NPT x 1-3/4” LG. SCH. 80 NIPPLE and 1-1/2” NPT 300# Union (Gilbarco part
numbers R11493-50 and Q10846-08)
3 3-Bolt Flange with flexible connector (order Gilbarco kit number K94194)
Installing the Fittings
To install the fittings, proceed as follows:
1 Apply a pipe sealant (that is approved for use with petroleum products) to the threads.
Do not use Teflon ® tape. Teflon tape may shred off and get caught within
components.
CAUTION
2 Hand-tighten, and then wrench-tighten approximately by another 3 turns. The pump body is
aluminum.
Do not overtighten inlet fittings. The pump body is made of aluminum.
Overtightening may strip pump threads.
CAUTION
3 Check for leaks (refer to the section “Troubleshooting Table” on page 29 ).
