SMS-458B Modem Protection Switch Revision 2
Cable Configuration MN/SMS458B.IOM
A–2
A.1.1 Equipment Inspection
A.1.1.1 Included Parts
Refer to Table A-1 for equipment need to cable the SMS-458B switch.
Note: Parts are not illustrated to scale.
Table A-1. Equipment List
Qty Description Qty Description
1 SMS-458B Modem Protection
Switch
1 CA/0755 Cable Assy
AR CA/0813-4 Cable Assy, BNC
1 CA/0953 Cable, Ground Strap
AR CA/6697-1 Cable Assy 50-Pin
For ECL/HSSI Interface
2 WI/17250 Power Cord
AR CA/7706-1. Cable Assy, 9 to 50-Pin
For G.703 Interface
