2.3.2 Remote Interface (J1, J2, J3)
The remote interface connectors provide serial remote interface to the switch.
For external control of the switch, an external controller can connect through J1
(EIA-485) or J2 (EIA-232).
The prime and backup modems connect to the switch through J3 (EIA-485), the modem
control interface connector. This connector provides a bus-type control interface,
required for system operation.
The remote interfaces connectors are 9-pin female D connectors, with screw locks for
mechanical security. The remote connector is a DCE interface.
EIA-485 EIA-232
Pin # Name Pin # Name
1 GND 1 N/C
2 N/C 2 RD (RX)
3 N/C 3 TD (TX)
4 +RX/TX 4 N/C
5 -RX/TX 5 GND
6 N/C 6 N/C
7 N/C 7 N/C
8 +RX/TX 8 N/C
9 -RX/TX 9 N/C
2.3.3 Online Status (J4, J5)
Connectors J4 and J5 provide the output for the modulator and demodulator backup
online status in form-C format.
J4 is for the modulator online status and J5 the demodulator online status.
