SMS-458B Modem Protection Switch Revision 2
Remote Control Specification MN/SMS458B.IOM
B–11
B. 16 Operational Status Commands (Faults)
Modulator
Operational
Faults Status Command:
Response: >add/MOF_’cr’
BU_OP-FLT_xxxx’cr’’lf’]
Where: x = 1 to 4 (prime mod numbers)
Backup Operation Faults
Note: Fault status data is only returned if fault
conditions exist.
Demodulator
Operational
Faults Status Command:
Response: >add/DOF_’cr’
BU_OP-FLT_xxxx’cr’
DL_FLT_yyycr’’lf’]
Where: x = 1 to 4 (prime mod numbers)
y = 1 to 4 or faulted downlink number 1 to 7
Backup Operation Faults
All Demods on Downlink “y” faulted
Note: Fault status data is only returned if fault
conditions exist.
M:N Switch
Fault Status
Summary Command:
Response: >add/MNF_’cr’
COM_FLT_xxxxByBy’cr’
CUC_FLT_xxxxByBy’cr’
MOD_CONFIG_FLT_xxxxByBy’cr’
DMD_CONFIG_FLT_xxxxByBy’cr’
MOD_COMPAT_FLT_xxxxByBy’cr’
DMD_COMPAT_FLT_xxxxByBy’cr’
+12V_FLT’cr’
-12V_FLT’cr’
+5VFLT’cr’
PS1_FLT’cr’
PS2_FLT’cr’
M&C_BAT_FLT’cr’
PARAMETER(S)_MISSING’cr’’lf’]
Where: x = 1 to 4 prime modem number
y = 1 or 2 backupmodem number
Modem communications faults
Channel unit communications faults
Mod configuration verify faults
Demod configuration verify faults
Mod compatibility fault
Demod compatibility fault
Power fault +12V
Power fault –12V
Power fault +5V
Power supply #1 fault
Power supply #2 fault
M&C battery fault
Missing parameter fault, use “MPF” command to
determine faults
Note: Fault status data is only returned if returned if
fault conditions exist.
Missing
Parameter
Faults Command:
Response: >add/MPF_’cr’
NO_MOD_COFIG_xxxxByBy’cr’
N0_DMD_CONFIG_xxxxByBy’cr’
NO_ADX_xxxxByBy’cr’
NO_CU_ADX_xxxxByBy’cr’
NO_DL_xxxxByBy’cr’’lf’]
Where: x = 1 to 4 prime modem number
y = 1 or 2 backup modem number
No modem communication loaded.
No demod communication loaded.
No address specified for modem.
No channel unit address specified.
No downlink specified for demod.
Note: Fault status data is only returned if returned if
fault conditions exist.
