OM20 Universal Outdoor Modem

Web Browser/Remote Protocol

MN-OM20– Revision 5

6–10

6.3.3 IP and Application Administration

The Modem Addressing menu provides instructions on how to configure the modem, applications
and PC.

6.3.3.1

Modem Addressing

Figure 6-6. Modem Addressing

Server Boot Mode:

{DEFAULT, NON-VOL, BOOTP, IP TEST}

Default: All of the following parameters as shown in Table 6-3
through 6-8 will be set and will not change until the boot mode is
changed.

IP

IPMASK:

255.000.000.000

MODEM IPADDR:

010.000.000.001

SERVER IP ADDR:

010.001.001.001

ROUTER IP ADDR:

010.000.001.001

Table 6-3. IP Parameters
