OM20 Universal Outdoor Modem Web Browser/Remote Protocol
MN-OM20– Revision 5 6–47
IMPORTANT
The status of the following ports may be one of the following:
Down: The link is down.
Unresolved: Unable to agree on connection speed.
10 Mbps Half: Connected at 10 Base-T Half Duplex.
10 Mbps Full: Connected at 10 Base-T Full Duplex.
100 Mbps Half: Connected at 100 Base-T Half Duplex.
100 Mbps Full: Connected at 100 Base-T Full Duplex.
PORT 1 STATUS {See the note above}
Displays the current status of LAN Port 1.
PORT 2 STATUS {See the note above}
Displays the current status of LAN Port 2.
PORT 3 STATUS {See the note above}
Displays the current status of LAN Port 3.
PORT 4 STATUS {See the note above}
Displays the current status of LAN Port 4.
WAN STATUS {See the note above}
Displays the current status of the WAN Port.
