Operation SLM-Series AC/DC Electronic Load
3-14 M540072-01 Rev B
Description SLM-60-20-300 SLM-150-8-300 SLM-300-4-300 SLM-500-1-300
MODE CC CC CC CC
LOAD OFF OFF OFF OFF
LEVEL LO LO LO LO
SENSE OFF OFF OFF OFF
PRES OFF OFF OFF OFF
WATT OFF OFF OFF OFF
LIMITS
V LIMIT High [V RMS ] 100.0 200.0 400.0 600.0
ALIMIT High [A RMS ] 25.00 10.00 5.000 2.000
WLIMIT High [W] 400.0 400.0 400.0 400.0
VALIMIT High [VA] 400.0 400.0 400.0 400.0
All Lower Limits 0.00 0.0 0.0 0.0
C.F √2 √2 √2 √2
FREQ [Hz] 60 60 60 60
BANK 0 0 0 0
SYNC OFF OFF OFF OFF
CC Level LO [A RMS ] 0.000 0.000 0.000 0.000
CC Level HI [A RMS ] 0.000 0.000 0.000 0.000
CR Level LO [ Ω] 4800 30E3 120E3 80E3
CR Level HI [ Ω] 4800 30E3 120E3 80E3
Table 3-3 SLM Series AC/DC Module Factory/Reset Settings
3.4.2 Load current course/fine increase/decrease adjustment key
The maximum load current of the SLM-Series AC/DC Electronic Load Modules can
be adjusted to 20.00A, 8.000A, 4.000A, or 1.000A, as depicted in Table 3-4.
The relationship between the adjustment variation of the load current or resolution
and their keys is also shown in Table 3-4. Pressing and holding any of the arrow
keys for more than one second, speeds the rate of changing the selected value.
SLM-60-20-300 Range 1 Range 2
FULL SCALE LOAD CURRENT 10 A 20 A
CURRENT RANGE 20.00 A
METER RESOLUTION 0.01 A
COURSE/FINE LOAD
CURRENT ADJUSTMENT KEY
↑↓ ↑↓
CC Mode 25 mA 2.5 mA 50 mA 5 mA
CR Mode 2.083mS 0.208mS 8.333mS 0.833mS
SLM-150-8-300 Range 1 Range 2
FULL SCALE LOAD CURRENT 4 A 8 A
CURRENT RANGE 8.000 A
METER RESOLUTION 0.001 A
COURSE/FINE LOAD
CURRENT ADJUSTMENT KEY
↑↓ ↑↓
CC Mode 10 mA 1 mA 20 mA 2 mA
CR Mode 0.333mS 0.033mS 1.333mS 0.133mS
